Introduce
Standard Configurations:
Yunnei YN27 engine 42kw, joystick, hub reduction axle, heater, loading bucket capacity 0.8m3, loading bucket load: 1.6t Digging bucket capacity: 0.25m3 VARTA battery, warning light, adjustable steering wheel and seat, bucket can be level automatic, back sound, radio, fan, hand brake, extinguisher, window hammer.
Optional Equipment:
Xinchai498 Euro 3 engine/Yanmar engine/Kohler EPA engine, rear view camera, quick hitch, pallet fork, 4th hydraulic line etc.
Specifications
| Transport Dimension | |
|---|---|
| LengthxWidthx Height (mm) | 8390×1960×2842 |
| Overall weight(kg) | 5000 |
| Rated loading weight (kg) | 1600 |
| Wheel base (mm) | 2080 |
| Engine model | Yunnei/Xinchai/Yanmar |
| Rated Power of Engine(kw) | 42/36.8/35.5 |
| Work Pressure (Mpa) | 16 |
| Tire | 20.5/70-16 |
| Loading bucket capacity | 0.7m3 |
| Rated Backhoe | 0.2m3 |
| Max. Digging Depth (mm) | 1930 |
| Max.Dumping height (mm) | 2655 |
| Dumping distance (mm) | 1110 |
| Turning Angle of Movable Arm | 180° |
