Introduce
Performance and characteristic
1. The use of a straight direct-injection water-cooling four-stroke engine produced by Ricardo’s technology ensures good starting performance in cold condition, strong power, reliable performance, efficiency and energy conservation
2. The design of the streamlined form is more attractive and modern.
3. The cab fully adopting tempered glass is safer for the wider visual field.
4. Adopting the improved elastic connection method, a novel instrument panel is installed to reduce vibration, ensuring operation is more convenient and comfortable.
5. The frame is optimally designed by the computer with high-quality steel, and the loader body is lengthened to make operation and driving more stable, safer, and more reliable.
Standard Configurations
Changchai 4G33TC engine 70kw, 4WD, 16/70-20 wider tires, joystick, standard bucket, VARTA battery, floating function, luxury cabin with heater, 220V engine preheat, warning light, adjustable steering wheel and seat, the bucket can be level automatic, back sound, radio, fan, hand brake, extinguisher, window hammer, free parts, toolbox. Standard with 3 hydraulic lines
Optional
Xinchai Euro V engine, Imported engines EPA 4/ Euro V, quick hitch, air conditioning, rearview camera, sliding window, electric floating, diesel heater, extra hydraulic lines, all kinds of attachments, etc.
Specifications
| Type | Data |
|---|---|
| Engine Model: | CHANGCHAI 4G33 |
| Rated Power(kw): | 70 |
| Rated Speed(rpm): | 2400 |
| Rated load(kg): | 1800 |
| Rated Bucket Capacity(m3): | 0.8-1.1 |
| Overall Size LxWxH(mm): | 5505×1950×2720 |
| Wheel base (mm): | 2515 |
| Wheel thread(mm): | 2430 |
| Max.breakout force (KN): | 72 |
| Max.dump height(mm): | 3300 |
| Dump distance(mm): | 470 |
| Total time(s): | 11.3 |
| Operating Weight(kg): | 4800 |
| Tyre: | 23.5-16 16/70-20 |
