Introduce
Standard configuration:
Xinchai C490BPG Euro 3 engine 36.8kw, 4WD, 20.5-16 tires, joystick,WL80S new cabin, standard bucket, VARTA Battery, floating function, luxury cabin with heater, new engine hood, 220V engine preheat, warning light, adjustable steering wheel and seat, bucket can be level automatic, back sound, radio, fan, hand brake, extinguisher, window hammer, Free parts, tool box.Standard with 3 hydraulic lines
Optional:
Imported engine, Quick Hitch, double heater, air conditioning, electric floating, extra Hydraulic Line, electronic joystick, different attachments etc.
Specifications
| Type | Data |
|---|---|
| Engine Model: | XINCHAI C490BPG E3 |
| Rated Power(kw): | 36.8 |
| Rated Speed(rpm): | 2650 |
| Rated load(kg): | 1200 |
| Rated Bucket Capacity(m3): | 0.4-0.6 |
| Overall Size LxWxH(mm): | 4750×1800×2600 |
| Wheel base (mm): | 2020 |
| Wheel thread(mm): | 1490 |
| Max.breakout force (KN): | 40 |
| Max.dump height(mm): | 2405 |
| Dump distance(mm): | 990 |
| Total time(s): | 9.5 |
| Operating Weight(kg): | 3400 |
| Tyre: | 20.5-16 |
