Introduce
Standard Configurations:
YTO 4108 turbo engine 85kw, 4WD, 16/70-24 tires, joystick, standard bucket, Varta Battery, floating function, luxury cabin with heater, 220V engine preheat, warning light, adjustable steering wheel and seat, bucket can be level automatic, back sound, radio, fan, hand brake, extinguisher, window hammer, free parts, tool box. Standard with 3 hydraulic lines; Lifting height 4200mm, dumping height 3600mm
Optional:
Dongfeng Cummins engine, quick hitch, air conditioning,rear view camera, diesel heater, extra hydraulic lines, all kinds of attachements etc.
Specifications
| Type | Data |
|---|---|
| Engine Model: | YTO YT4A4Z-24 |
| Rated Power(kw): | 85 |
| Rated Speed(rpm): | 2400 |
| Rated load(kg): | 2800 |
| Rated Bucket Capacity(m3): | 1.2-1.5 |
| Overall Size LxWxH(mm): | 6500×2100×3050 |
| Wheel base (mm): | 2530 |
| Wheel thread(mm): | 2000 |
| Max.breakout force (KN): | 112 |
| Max.dump height(mm): | 3600 |
| Dump distance(mm): | 1084 |
| Total time(s): | 9.3 |
| Operating Weight(kg): | 6500 |
| Tyre: | 16/70-24 |
