Specifications
| Engine | |
|---|---|
| Model | Laidong KM385B 18.1kW/2200rpm
KUBOTA D1105 14.2kw/2200rpm |
| Type | Direct injection, water cooled, natural intake |
| No. of cylinder | 3 |
| Main Performance | |
| Swing Speed (r/min) | 10-12 |
| Traveling Speed (km/H) | 2.8 |
| Grade ability (%) | 70(35°) |
| Traveling Tracking Force (kN) | 15 |
| Bucket Digging Force (kN) | 11.5 |
| Arm Digging Force (kN) | 9.3 |
| Hydraulic System | |
| Hydraulic system working pressure (Mpa) | 16 |
| Hydraulic Pump (Gear Pump) | TJHD |
| Hydraulic pump flow (L/min) | 2×22+8.8 |
| Swing Motor | Eaton |
| Traveling Motor | Eaton |
| Fuel Tank Capacity (L) | 26 |
| Hydraulic Tank Capacity (L) | 27 |
| Overall Dimensions | |
| Overall Length (mm) | 3800 |
| Overall Width (mm) | 1050 |
| Overall Height (mm) | 2280 |
| Ground clearance (mm) | 485 |
| Track length (mm) | 1630 |
| Track width (mm) | 230 |
| Undercarriage width (mm) | 1050 |
| Undercarriage ground clearance (mm) | 235 |
| Dozer Blade (mm) | 1050×240 |
| Operation parameters | |
| Operation Weight (KG) | 1800 |
| Bucket Capacity (m3) | 0.1 |
| Max. Digging Radius (mm) | 3860 |
| Max. Digging Depth (mm) | 2050 |
| Max. Digging Height (mm) | 3370 |
| Max. Dumping Height (mm) | 2390 |
| Max. Dozer Cutting (mm) | 270 |
| Max. Dozer Lifting (mm) | 235 |
| Boom Deflexion (Left/Right) (°) | 75/45 |
| Tail Swing Radius (mm) | 1125 |
| Front Min. Swing Radius (mm) | 1720 |
