Specifications
| Operating Weight | 1600kg |
| Digging bucket capacity | 0.045cbm/400kg |
| Digging bucket width | 400mm, can add narrow bucket is 200mm |
| Engine | Yanmar 3TNV70 |
| Rated power | 10kw/2200/r/min |
| Displacement | 0.854L |
| Bore stroke | three cylinder, water coo |
| Main pump | PERMCO |
| Valve | PERMCO |
| Displacement | 6.8ml/r |
| Swing motor | EATON |
| Traveling motor | KERSEN |
| MAIN DIMENSIONS | |
| Overall dimension( LxWxH) | 3290×1050×2400mm |
| Total length of track on land | 1670mm |
| Platform ground clearance | 460 mm |
| Platform back turning radius | 740 mm |
| Chassis width | 1050 mm |
| Track width | 180 mm |
| Chassis ground clearance | 460 mm |
| Track height | 410 mm |
| OPERATING RANGE | |
| Max. Digging depth | 2150 mm |
| Max. Vertical digging depth | 1740 mm |
| Max. Digging height | 2275 mm |
| Max. Dumping height | 2310 mm |
| Max. Digging radius on ground | 3470 mm |
| Min. Rotation radius | 1440 mm |
| Max. Upgrade height of bulldozer blade | 285 mm |
| Max. Digging depth of bulldozer blad | 195 mm |
