Specifications
| Engine | |
|---|---|
| Model | YANMAR 3TNV80F |
| Rated power | 15.2kw |
| RPM | 2500 r/min |
| Displacement | 1.267 L |
| No. of cylinder | 3 |
| Main Performance | |
| Swing Speed (r/min) | 10.5 |
| Traveling Speed (km/H) | 2.0/3.8km/h |
| Grade ability (%) | 58% |
| Max. Bucket Digging Force (kN) | 24.5 |
| Arm Digging Force (kN) | 14.8 |
| Bucket Digging Force (kN) | 9 |
| Ground Pressure (Kpa) | 31 |
| Hydraulic System | |
| Hydraulic system working pressure (Mpa) | 22 |
| Machine Weight (KG) | 2650/2700 |
| Max. flow (L/min) | 67.2 |
| Fuel Tank Capacity (L) | 35 |
| Hydraulic Tank Capacity (L) | 42 |
| Overall Dimensions | |
| Overall Length (mm) | 4159 |
| Overall Width (mm) | 1500 |
| Overall Height (mm) | 2500 |
| Mini Ground clearance | 320 |
| Track width (mm) | 1550 |
| Axle base(Track length on ground)(mm) | 2040 |
| Track Gauge(mm) | 1250 |
| Swing radius at tail (mm) | 775 |
| Swing radius at front (mm) | 2096 |
| Counterweight ground clearance(mm) | 535 |
| Turntable width (mm) | 1550 |
| Track shoe width (mm) | 250 |
| Operation parameters | |
| Bucket Capacity (m3) | 0.08 |
| Max. Digging Radius (mm) | 4610 |
| Max. Digging Depth (mm) | 2485 |
| Max. Digging Height (mm) | 4132 |
| Max. Dumping Height (mm) | 2742 |
| Max. vertical digging depth (mm) | 2240 |
