Introduce
1. Reinforced chassis design to withstand the roughest terrains and extreme climatic conditions
2. Newly designed engine cover for better access to the engine bay for easy maintenance
3. Wide range of attachments to perform different applications
4. High levels of customizations can be made to suit the requirements of end-users from various industries
Standard Configurations:
Changchai 4G33 engine 70kw, electronic control joystick , LED lights, back camera, Varta Battery, 16/70-20 tires,3 hydraulic lines, floating function, luxury cabin with heater, 220V engine preheat, warning light, adjustable steering wheel and seat, bucket can be level automatic, back sound, radio, fan, hand brake, extinguisher, window hammer, Free parts, tool box.
Optional :
Imported engine with Euro V or EPA Tier 4 standards, Quick Hitch, double heater, air conditioning, electric floating, extra Hydraulic Line, fully electronic joystick, different attachments etc.
Specifications
| Type | Data |
|---|---|
| Bucket Capacity (Cbm): | 1.0-1.2 |
| Rated Load (Kg): | 2500 |
| Overall Weight (Kg): | 5000 |
| Dumping Clearance (mm): | 2850 |
| Standard Engine: | CHANGCHAI 4G33 |
| Rated Power (Kw): | 70 |
| Rated Speed (R/Min): | 2400 |
| Optional Engine: | XIN CHAI E5/CUMMINS |
| Wheel Base (mm): | 1550 |
| Tread (mm): | 2550 |
| LX WXH (mm): | 6100×2100×2580 |
| Standard Tire: | 16/70-20 |
| Max. Driving Speed (km/h): | 20-30 |
